RICOSMA CRUISER Sprayer 3700

Cruiser trailed sprayers, designed by «LAMIA GROUPLIMITED» , made in Russia

Basic equipment:

Type
trailed sprayer for application by spraying aqueous solutions of herbicides, fungicides and other chemical solutions.

Frame
reinforced, painted with chemically resistant paint in black. Drawbar — 50 mm, platform with ladder. Jack.

Rod
composite 24 meters, hydraulically folded, collision protection, mechanical compensation, reinforced. Painted with chemically resistant green paint. Autonomous hydraulic control system for boom functions. Hydraulic lock. The boom lifting height (from sprayers to the ground surface) is 0.5 — 2.0 m. The boom lifting system has pneumatic shock absorbers that effectively dampen vibrations when driving over rough terrain.

The sprayer has its own autonomous hydraulic system that allows it to work independently of the tractor hydraulic system. Boom hydraulic control directly from the motion computer. Mounting nozzles with the simultaneous installation of three different nozzles (3 sets of nozzles included).

Capacity
plastic solid 3700 l., with a hinged lid with a float valve, green color, flushing tank — 350 l. with yellow lid, handwashing container – 15 l. color yellow, mixer for mixing concentrates — 35 l. yellow color. Graduated liquid level scale.

Working fluid supply system
diaphragm type pump (IP D-203), a system for preparing a solution for liquid and bulk concentrates with hydraulic mixers, a tank injection system, a multi-stage filtration system. Possibility of autonomous filling of containers. Pump performance — 209 l / min.

Electronic control system for the supply of working fluid, control over the consumption rate, changing parameters in motion, counting the areas of NK Agronavigator plus with ASUR sectional shutdown.

Wheels
standard size 230/95 R48

Overall dimensions
Adjustable track, m — 1.4 — 1.8 stepless. Width, mm -2255. Height, mm — 3122. Length, mm — 6730

Wide Angle Drive Shaft (PTO) 8G2R141CEWR6002
